Niobec in Québec is one of only three mines globally that primarily extract niobium, with grades between 0.37% and 0.6% Nb2O5. (Source)

Saville Resources Inc. today announced the filing of an independent NI43-101 Technical Report on the Niobium Claim Group Property in Québec, Canada.

Shareholders and investors alike should take a close look at the “Conclusions and Recommendations“ section, which starts as follows:

“The Property is considered to have a strong potential for discovery of carbonatite hosted niobium-tantalum-(phosphate) deposit(s) of significance, as well as for fluorite. The Author considers niobium-tantalum to be of primary interest, with fluorspar (fluorite) and phosphate as secondary commodities.“

As successful investors in the mining space know by heart, it‘s the discovery of a deposit which provides the largest upside potential as this phase typically creates most shareholder value.

Although Saville has not done any exploration yet, the company is getting ready to drill – based on 10 years of previous work by Commerce Resources Corp., including drilling of 41 holes. This demonstrates that it‘s not an early-stage project and that vast upside exists for Saville to unlock for its shareholders; especially when considering that Saville has a current market capitalization of less than $3 million CAD with a pretty tight share structure of around 47 million shares in the market.

What makes Saville‘s project so attractive are not only the high niobium and tantalum grades over significant widths thus far observed, but also the strong potential of fluorspar and phosphate occurrences.

The Trump Administration has deemed niobium, tantalum, and fluorspar critical for economic and national security as the US remains 100% net import reliant on these commodities, which are also included in the new tariff regime.

Phosphate rock ore was mined by only 5 firms in the US last year, processing it into marketable products valued at $2.1 billion USD for 100% domestic use as intermediate feedstocks in the manufacture of fertilizers and animal feed supplements, according to USGS.

The tantalum market is quite bizarre, however this is not on the demand side but on the supply side. Most of the world‘s tantalum continues to come from unattractive locations like the Democratic Republic of the Congo

The opportunities in today‘s niobium market are huge (the market is growing by 8-10% per year), with most niobium going to the manufacture of High Strength Low Alloy (HSLA) steel. This HSLA steel is used in building and bridge construction or to the manufacture of stronger but lighter steel chassis for most cars, whether they are Internal Combustion (IC) engine vehicles or Electric Vehicles (EVs) because of the benefits of increasing fuel economy or extending battery range.

The global niobium market continues to be supplied by only 3 mines, and there have been no new additions brought into production since late 2006 when the market price quadrupled. One of the reasons for this lack of producers, which may not be well known, is that niobium deposits can have metallurgical complications, especially if these are not hosted by a carbonatite which host rock‘s simple mineralogy enables conventional processing. The 3 primary niobium mines currently in production are all hosted by carbonatite.

Most interestingly, the Saint-Honoré Carbonatite in Québec not only hosts the Niobec Mine but also a large REE Zone of more than 450 million tonnes at a grade of 1.65% TREO. In other words: It was the niobium deposit which went into production first, although the core of the carbonatite consists of REE mineralization. Who sees a striking resemblance with the Eldor Carbonatite?


Above cross-section (Simandl & Mackay, 2014) of Québec‘s Saint- Honoré Carbonatite, which hosts the Niobec Mine, illustrates that the general geology is similar to the Eldor Carbonatite, which hosts the high-tonnage Ashram REE Deposit and the adjoining Niobium Claim Group Property.


Full size

As a matter of fact, Saville‘s neighbor Commerce Resources Corp. has historically worked with one of the most respected experts in the world of niobium, Michel Robert, who set up the flow sheet for Niobec and who ran the mine for 4 years before it was bought by IAMGOLD Corp., which later sold the mine to a consortium of Asian investment firms for $530 million USD in 2014.

According to today‘s news:

“The Southeast Area is the most advanced prospect on the Property with drill intercepts including 0.82% Nb2O5 over 21.9 m and 1.09% Nb2O5 over 5.8 m in drill holes EC10-033 and 040, respectively. These strongly mineralized intercepts have yet to be followed-up and, along with Miranna, are high-priority exploration targets for the Company.

The drilling at the Star Trench Area ... has returned some of the strongest tantalum drill intercepts to date on the Property, including 454 ppm Ta2O5 over 7.8 m and 632 ppm Ta2O5 over 3.8 m in drill hole EC08-025. These drill intercepts, also associated with moderate niobium and strong phosphate mineralization, were returned from relatively shallow depths (1.69% Nb2O5, 2,220 ppm Ta2O5, and 20.5% P2O5 over 0.3 m (sample 84321).“

As most of the current niobium exploration, development, and mining projects have resource grades below 1% Nb2O5, Saville aims to delineate a large and high-grade niobium deposit to earn the status of a world-class project.

The author of the Technical Report recommends the following:

“Based on the favourable geologic setting, abundant niobium-tantalum mineralized boulders found on surface, and in historic drill holes, as well as other targets remaining to be fully explored, the Niobium Claim Group Property is considered of sufficient geological merit to warrant further exploration. A two-phase exploration approach is proposed. Phase I is recommended to focus on refining drill targets and include geologic modelling of historic drill intercepts, and surface follow-up (e.g. prospecting, trenching, ground geophysics). Phase II is recommended to include diamond drilling (6,000 m) to test new targets, as well as further evaluate and expand known mineralized horizons. Work overall is recommended to focus on the Southeast Area, where the strongest potential has been identified, as well as the Miranna Target. The estimated budget is $693,000 for Phase I and $5,132,000 for Phase II, for a combined total budget of $5,825,000.“

In mid-August, Saville closed the first tranche of a non-brokered financing for gross proceeds of $877,700 CAD. The second tranche has not closed yet and has the same conditions: Flow-through shares for $0.06 CAD and non-flow-through shares for $0.05 CAD; the latter comes with a full warrant exercisable at $0.10 CAD for a period of 24 months. Saville currently trades at $0.055 CAD on the TSX Venture Exchange.

As per today‘s news, Saville is currently in the late stages of planning a fall exploration program, consisting of prospecting and rock sampling, and a ground magnetic survey to further delineate the mineralized horizon. The primary objective of this program is to further refine drill hole locations ahead of drilling planned for the first half of 2019.


Full size


Full size

Excerpts from the newly filed NI43-101 Technical Report, which is available on SEDAR or here (below accentuation by Rockstone):

“The relatively high niobium-tantalum values are ubiquitous throughout the carbonatite and phoscorite within the Property; however, the higher-grade occurrences of primary interest are interpreted to be present in the outer portions of the Eldor Carbonatite Complex, and have been sampled in the northwestern, eastern, and southeastern portions...

In general, based on current surface, drill hole, and geophysical data, mineralization located in the Southeast Area is interpreted to be up to 1 km in length and occur over several 100 m in width. However, this mineralized occurrence remains poorly delineated with a significant amount of drilling required to better understand continuity, extent, and controls on the mineralization...

Historic exploration of the Niobium Claim Group Property has defined several prospective areas including the Southeast Area, the Northwest Area, the Star Trench Area, and more recently the Miranna Area. The Southeast, Northwest, and Star Trench areas have been the subject of drill programs in 2008, and the Southeast and Star Trench areas again in 2010.


Full size / A total of 41 drill holes, totalling 8,175 m, have been completed on the Niobium Claim Group Property, primarily testing niobium and tantalum targets as developed from historic work (2008, 2010, 2011, and 2015).

The assay data indicate that the Southeast Area is host to higher grades of niobium-tantalum over larger widths when compared to other areas on the Property, while also hosting a large number of other targets to follow-up as well as new ones to test.  Therefore, the Author considers the Southeast Area to hold the strongest potential for hosting a niobium-tantalum deposit of appreciable grade and tonnage on the Property and recommends that this area initially remain the focus of exploration. This is highlighted by the wide intercept starting from 4.22 m depth in EC10-033 (0.72% Nb2O5 over 21.35 m), which demonstrates higher-grade mineralization essentially reaches surface. This interval also includes the highest niobium-grade drill core sample collected to date at 1.85% Nb2O5 and 720 ppm Ta2O5 (over 0.48 m) at 24 m depth. The highest-grade niobium intercept to date was also returned from the same area with 1.09% Nb2O5 over 5.84 m in EC10-040. The Southeast Area also hosts potential for fluorite with several well-mineralized intercepts over ~20 m returned in past drilling...

Significant fluorspar mineralization was also intersected in the Southeast Area, including 14.95% fluorine (~30.7% fluorspar) over 22.29 m...

The highest-grade niobium [prospecting rock] sample from the Southeast Area returned 1.18% Nb2O5 and 0.036 Ta2O5, and up to 19.2% P2O5...

The highest niobium grade from rock samples collected in 2008 in the Northwest Area exceeded detection limit at 7.15% Nb2O5, with the best overall sample returning 5.73% Nb2O5 and 0.456% Ta2O5% (highest Ta grade of program). Samples up to 27.6% P2O5 were also collected in the Northwest Area...

Drilling to date at the Star Trench Area suggest its size potential may limited; however, the area is also host to the highest grades of tantalum on the Property and requires further ground work ahead of additional drill testing...


Full size

The Miranna Area exploration is less advanced, being limited to surface prospecting and sampling to date. A well mineralized, northwest-southeast oriented, elongated Ta-Nb mineralized boulder field has been traced for ~1 km. A number of sources for this mineralized train are possible, including a nearby magnetic anomaly (the “Miranna Target”). The Miranna Target is considered a high priority for further work including possible drill testing.

In addition to the Miranna Target, the 2011 prospecting program produced the most highly mineralized sample obtained do date on the Property, as well as the entire Eldor Carbonatite Complex, with an assay of 16.1% Nb2O5 and 0.754% Ta2O5. The boulder was collected west of the Northwest Area, near the Property border, within claim 1007883. The source of this boulder is difficult to determine as it is relatively isolated in occurrence; however, ice direction suggests a source to the southeast, probably within the complex...

The PANDS Showing was discovered in 2011, located just south of Glim Lake, on what has since been known as the PANDS Area. The area was found to host significant outcrop, which is unusual for the Property. A sample collected from outcrop in this area returned 0.41% Nb2O5 and 0.066% Ta2O5, in addition to a nearby boulder sample, which returned 3.94% Nb2O5 and 0.251% Ta2O5. The initial interest in the area was for its REE potential, with sample up to 3.0% REO collected; however, the Nb-Ta results have not been followed-up...

Historic exploration of the [Eldor] complex has shown it to have an elliptical shape with approximate dimensions of 7.3 km long by 3 km wide (Sherer, 1984). More recently, Clark and Wares (2006) suggested a carbonatite extent of almost double, at 15 km long by 4 km wide. Deformation at about 1.8 Ga tilted the region and resulted in a regional dip to the northeast for the carbonatite complex...

The target deposit type at the Property is a Nb-Ta-Phosphate enriched carbonatite ± fluorite, hosted within certain phases of the Eldor Carbonatite Complex. At Eldor, the mineralized zones of interest are concentrated in the outer parts of the complex and occur in sills and dikes of crosscutting earlier primary carbonatite. These zones have been interpreted on the Property to dominantly strike to the northwest and dip moderately to steeply to the northwest.

Through 2008, there have been 527 documented carbonatites globally (Woolley & Kjarsgaard, 2008), of which, numerous have attained production for a variety of commodities. These include rare earth elements (REEs), niobium, iron, copper, apatite, and fluorite (Schulz, K. J.; Piatak, N. M.; Papp, J. F.; 2017).

Moreover, the dominant source of REEs and niobium in the world is from carbonatite deposits. Therefore, carbonatites are well-regarded as an excellent target for mineral exploration, especially for niobium, which is of primary interest to the Company...

Global examples of carbonatite hosted niobium deposits include the operating Niobec Mine within the Saint-Honoré Carbonatite, Canada, the past producing St. Lawrence Mine within the Oka Carbonatite, Canada, and the Crown Deposit within the Mount Weld Carbonatite, Australia. The global niobium market is almost entirely supplied by ... carbonatite hosted mines; predominantly the Araxa Mine in Brazil, and to a lessor extent the Niobec Mine in Canada.“


Full size

Option Agreement

Saville‘s Niobium Claim Group Property is under Exploration Earn-in Agreement from Commerce Resources Corp., whereby Saville may earn up to a 75% interest, subject to certain terms and conditions including TSX Venture Exchange Approval. The total land position of the Niobium Claim Group Property includes 26 claims over 1,223 hectares.
